10Kwh Solar Lithium Ion Battery 48V 200ah Lifepo4 Powerwall Battery Storage

Product Categories

guangzhou pmd technology co ltd

Contact Now

Place of Origin : china

MOQ : negotiated

Price : negotiated

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Delivery Time : negotiated

Battery Type : Lithium Ion

Nominal Voltage : 48V

Nominal Capacity : 10KWH

Warranty : 12 Years

Cycle life : 6000 Times

MAX Constant Charge Current : 100A

Contact Now

Product Description

Specification

Powerwall Home Battery Datasheet
1	Nominal Voltage	48V (51.2V)
2	Nominal Capacity	100AH, 150AH, 200AH
3	Nominal Energy	5KWH, 7.5KWH, 10KWH
4	Batetry Type	Lithium Ion
5	BMS	Built-in BMS
6	Operation Temperature	Discharge: -20℃-60℃(pack internal temperature)
7	Operation Voltage Range	43.2～58.4V
8	MAX Constant Charge Current	100A
9	MAX Constant Discharge Current	120A, 500A(3S), 750A(1S)
10	Efficiency	98%
11	Cycle Life (100% DOD)	>3000 cycles (100% DOD); >6000 cycles (80% DOD)
12	Size	L 485mm * W 240mm * H 660mm
13	Battery Cell	18650 Type (UN38.3, UL 1642, CE)
14	Battery Pack	Comply UN38.3, CE
15	Communication	Can-bus, RS 485
16	Others	LCD Screen, Max 14pcs Connect in Parallel
10 Years Warranty, More than 20 Years Lifetime
